Vsh Fabrieken Xpr stainless elbow 45 deg. øf 15

VSH 45° bend nipple/muff in 15mm acid-resistant stainless steel. Product description: VSH X Press in stainless steel is a complete system of fittings and pipes ranging from 15mm to 108mm for installations of domestic water, rainwater, softened/decalcified water, desalinated water, distilled water, heating systems and cooling systems. Benefits: Can be pressed with most brands of universal M-profile pressing tools. Complete system program with fittings, pipes and valves. Approved according to DVGW work diagram W534. Very precise tolerances make the pipe easy to insert into the fittings. Pressure testing of all welded parts. VA approved. Suitable for all pipe types that comply with DIN 17455.Technical characteristics:Material:Pipe and fittings: AISI 316 (1.4401)O-ring: EPDM (LBP) Leak Before PressedApplication area:Media: WaterTemperature range: -20/+110 CPressure range: Max.16 barProduct family:VSH XPress in galvanized steel is a complete system of fittings and pipes ranging from12 mm to108 mm for heating and cooling systems.Benefits:Can be pressed with most brands of universal M-profile pressing tools.Complete system program with fittings, pipes and valves.O-ring with leak before pressed.Laser-welded joints.All welded joints are pressure tested.Very precise tolerances make the pipe easy to insert into the fitting s .Suitable for all pipe types that comply with EN10305-3 (formerly DIN2394).Technical characteristics :Material :Fittings Galvanized Steel RSt34-2Packing EPDM leak before pressed (LBP)Application area :Media : WaterTemperature range : -20/+110 C Pressure range : Max .16 bar Technical specifications :Weight :0 .042 Dimension :15mm
