TRENDnet TEG-7124WS 12-Port 10G Web Smart Switch

Original price €667,66 - Original price €667,66
Original price
€667,66
€667,66 - €667,66
Current price €667,66
Availability:
12 in stock, ready to be shipped

Free returns on all eligible orders

You have 30 days to request a return. All sale items are final sale.

Switch, Smart, 8 x 10GBase-T + 4 x 10 Gigabit SFP+, an Rack montierbar, TAA-konform

Günstigste Versandoption 4,99 €
Verfügbar - 4-6 Werktage Lieferzeit
TRENDnet's 10G Web Smart Switch, model TEG-7124WS offers advanced traffic management controls to meet the evolving demands of SMB networks. This rack mountable IPv6-ready managed switch comes with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature. Free up router resources by offloading routing processes to this managed switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. TRENDnet's 10G web smart managed switch also features eight 10GBASE-T Ethernet ports, and four 10G SFP+ slots for high-speed network uplinks or downlink NAS/access server connections providing a cost-effective solution in adding 10G link capability to an SMB network.

Generell

Hersteller TRENDnet
Waren-Nr. 3308865
Modell TEG-7124WS
EAN 0710931140897
Zum Hersteller www.trendnet.com
Produktbeschreibung TRENDnet TEG 7124WS - Switch - 12 Anschlüsse - Smart - an Rack montierbar - TAA-konform
Gerätetyp Switch - 12 Anschlüsse - Smart
Gehäusetyp An Rack montierbar 1U
Untertyp 10 Gigabit Ethernet
Ports 8 x 10GBase-T + 4 x 10 Gigabit SFP+
Leistung Switching-Kapazität: 240 Gbit/s Weiterleitungsrate (64‑byte Pakete): 178,56 Mpps
Größe der MAC-Adresstabelle 32.000 Einträge
Jumbo-Rahmenunterstützung 10KB
Routing Protocol IGMPv2, IGMP, IGMPv3, MLDv2, MLD
Remoteverwaltungsprotokoll SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2, CLI
Leistungsmerkmale VLAN-Unterstützung, IGMP Snooping, Port-Spiegelung, IPv6-Unterstützung, Halbduplex-Modus, Vollduplex-Modus, STP Support, RSTP-Unterstützung, MSTP Support, QoS, MLD-Snooping, LACP-Support, GVRP, statisches Routing, CoS, SP, gekennzeichnetes VLAN, DoS, Metallgehäuse, Bandbreitensteuerung pro Port, DSCP-Unterstützung, Static Link Aggregation, 1 Ventilator, Voice VLAN, LLDP-MED, Private VLAN, WRR, HOL Blocking Prevention, Loopback-Erkennung, unbekannten Multicast blockieren, Unterstützung für Warteschlangenplanung
Produktzertifizierungen IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz
Stromversorgung Wechselstrom 100-240 V (50/60 Hz)
Abmessungen (Breite x Tiefe x Höhe) 32.5 cm x 23 cm x 4.4 cm
Gewicht 1.96 kg
TAA-kompatibel Ja

Technische Daten

Allgemein
Gerätetyp Switch - 12 Anschlüsse - Smart
Gehäusetyp An Rack montierbar 1U
Untertyp 10 Gigabit Ethernet
Ports 8 x 10GBase-T + 4 x 10 Gigabit SFP+
Leistung Switching-Kapazität: 240 Gbit/s Weiterleitungsrate (64‑byte Pakete): 178,56 Mpps
Größe der MAC-Adresstabelle 32.000 Einträge
Jumbo-Rahmenunterstützung 10KB
Routing Protocol IGMPv2, IGMP, IGMPv3, MLDv2, MLD
Remoteverwaltungsprotokoll SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2, CLI
Verschlüsselungsalgorithmus TLS, SSL 3.0, SSL 2.0
Authentifizierungsmethode RADIUS, TACACS+
Leistungsmerkmale VLAN-Unterstützung, IGMP Snooping, Port-Spiegelung, IPv6-Unterstützung, Halbduplex-Modus, Vollduplex-Modus, STP Support, RSTP-Unterstützung, MSTP Support, QoS, MLD-Snooping, LACP-Support, GVRP, statisches Routing, CoS, SP, gekennzeichnetes VLAN, DoS, Metallgehäuse, Bandbreitensteuerung pro Port, DSCP-Unterstützung, Static Link Aggregation, 1 Ventilator, Voice VLAN, LLDP-MED, Private VLAN, WRR, HOL Blocking Prevention, Loopback-Erkennung, unbekannten Multicast blockieren, Unterstützung für Warteschlangenplanung
Produktzertifizierungen IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz
Statusanzeiger Stromversorgung, Link/Aktivität/Geschwindigkeit, Fehler
Erweiterung/Konnektivität
Schnittstellen 8 x 10Gbit-LAN RJ-45 4 x 10Gbit-LAN SFP+ 1 x Konsole RJ-45
Stromversorgung
Stromversorgungsgerät Internes Netzteil
Erforderliche Netzspannung Wechselstrom 100-240 V (50/60 Hz)
Leistungsaufnahme im Betrieb 152.3 Watt
Verschiedenes
MTBF 590,929 Stunden
Produktzertifizierungen UL, FCC, NDAA
TAA-kompatibel Ja
Maße und Gewicht
Breite 32.5 cm
Tiefe 23 cm
Höhe 4.4 cm
Gewicht 1.96 kg
Umgebungsbedingungen
Min Betriebstemperatur 0 °C
Max. Betriebstemperatur 50 °C
Zulässige Luftfeuchtigkeit im Betrieb 90 % (nicht kondensierend)
