Philips Hf-p 236 tl-d / pl-l

Spole HF-P 236 TL-D / PL-L Product Description: Product • Energy-efficient, electronic high-frequency ballast for TL-D fluorescent tubes Features and Benefits • Energy-efficient CELMA A2 • ENEC and CE approved, in accordance with all relevant international safety and performance standards • Robust design for a lifetime of 50,000 hours at Tcmaxand over 60,000 on/off cycles on one light source • Programmed, flicker-free preheated start (<1.6 sec.) allows the fluorescent tube to be turned on and off without reducing its lifespan (e.g. for use in combination with lighting control components) • High power factor of 0.99 with THD <10% • Automatic restart after voltage drop or fluorescent tube replacement Suitable for emergency DC operation at 186 V to 275 V (at 10 C), in line with IEC/EN60598-22 High frequency operation reduces eye strain caused by electromagnetic ballasts EMC compliant with EN55015:2006+A1:2007 The unit is protected against excessive mains voltage and incorrect connections Active power factor correction of constant light levels regardless of fluctuations in mains voltage Universal connector designed for horizontal manual and push-in robot cable routing as well as vertical ALF robot cable routing Application Ideal for applications where high energy efficiency is desired Used with motion detection control systems such as Philips OccuPlus In office buildings, hospitals, supermarkets, department stores and schools In class I outdoor applications such as industrial plants and parking lots For emergency lighting purposes Technical Specifications Width (mm):206 Height (mm):87 Voltage(V):220-240 Length(mm):328
