Hikvision Pro Series DS-3E0505HP-E - switch - 5 ports - unmanaged

Original price €311,14 - Original price €311,14
Original price
€311,14
€311,14 - €311,14
Current price €311,14
Availability:
In stock

Free returns on all eligible orders

You have 30 days to request a return. All sale items are final sale.

The Hikvision Pro Series DS-3E0505HP-E is a switch designed to meet the demands of modern networking. Equipped with five ports, including three 10/100/1000 (PoE) ports and one high-power port, this switch supports a Power over Ethernet budget of 60 W and is capable of delivering a power output of 60 W for seamless connectivity and optimal performance. The metal housing combined with a fanless design ensures durability and quiet operation, making it suitable for a variety of environments. With an operating temperature range from -10°C to 40°C and a storage temperature range from -40°C to 85°C, it functions effectively in diverse conditions, ensuring reliability regardless of external factors. Featuring advanced capabilities such as full duplex mode, auto-uplink, port isolation, and a 6KV ESD protector, this switch is built to enhance networking efficiency and security. The compact desktop form factor allows for easy placement in any setup. Compliance with multiple standards such as IEEE 802.3 and RoHS ensures that the device is safe and reliable, catering to stringent regulatory requirements. With status indicators for power, link activity, and PoE max, users can efficiently monitor the device's performance.

Generell
Hersteller: Hikvision
Waren-Nr.: 3204372
Modell: DS-3E0505HP-E
EAN: 6941264031604
Zum Hersteller::
Produktbeschreibung: Hikvision Pro Series DS-3E0505HP-E - Switch - 5 AnschlĂŒsse - unmanaged
GerĂ€tetyp: Switch - 5 AnschlĂŒsse - unmanaged
Untertyp: Gigabit Ethernet
Ports: 3 x 10/100/1000 (PoE) + 1 x 10/100/1000 (Hi-PoE) + 1 x 10/100/1000
Power Over Ethernet (PoE): High PoE / PoE
PoE-Budget: 60 W
Leistung: Switching-KapazitÀt: 10 Gbit/s Paket Weiterleitungsrate: 7,44 Mpps
GrĂ¶ĂŸe der MAC-Adresstabelle: 2000 EintrĂ€ge
Leistungsmerkmale: Vollduplex-fĂ€hig, Auto-Uplink (Auto MDI/MDI-X), Store-and-Forward, ohne LĂŒfter, Anschlussisolierung, 6KV ESD Protector, MetallgehĂ€use
Produktzertifizierungen: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3bt
Abmessungen (Breite x Tiefe x Höhe): 12.1 cm x 8.81 cm x 2.76 cm
Gewicht: 270 g

Allgemein
GerĂ€tetyp: Switch - 5 AnschlĂŒsse - unmanaged
GehÀusetyp: Desktop
Untertyp: Gigabit Ethernet
Ports: 3 x 10/100/1000 (PoE) + 1 x 10/100/1000 (Hi-PoE) + 1 x 10/100/1000
Power Over Ethernet (PoE): High PoE / PoE
PoE-Budget: 60 W
Leistung: Switching-KapazitÀt: 10 Gbit/s Paket Weiterleitungsrate: 7,44 Mpps
GrĂ¶ĂŸe der MAC-Adresstabelle: 2000 EintrĂ€ge
Leistungsmerkmale: Vollduplex-fĂ€hig, Auto-Uplink (Auto MDI/MDI-X), Store-and-Forward, ohne LĂŒfter, Anschlussisolierung, 6KV ESD Protector, MetallgehĂ€use
Produktzertifizierungen: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3bt
Statusanzeiger: Stromversorgung, Link/AktivitÀt, PoE max
Erweiterung/KonnektivitÀt
Schnittstellen: 3 x 1000Base-T RJ-45 PoE - 30 W 1 x 1000Base-T RJ-45 HPoE - 60 W 1 x 1000Base-T RJ-45
Stromversorgung
StromversorgungsgerÀt: Externer Netzadapter
Gestellte Leistung: 48 V - 1.35 A
Leistungsaufnahme im Betrieb: 65 Watt
Stromverbrauch im Standby-Modus: 5 Watt
Verschiedenes
Produktzertifizierungen: IC, UL 60950-1, FCC CFR47 Part 15 B, RCM, RoHS 2011/65/EU, EN 61000-3-3:2013, WEEE 2012/19/EU, EN 61000-3-2:2014, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55024:2010+A1:2015, EN 55032:2015, REACH 2006/1907, AS/NZS CISPR 32:2015, EN 60950-1:2005+Am1:2009+Am 2:2013, ICES-003 issue 6:2016
Maße und Gewicht
Breite: 12.1 cm
Tiefe: 8.81 cm
Höhe: 2.76 cm
Gewicht: 270 g
