Lenovo ThinkSystem EIOM module
Netzwerkadapter, LAN-on-motherboard (LOM), 10Gb Ethernet x 8, für ThinkAgile HX3721 Certified Node 7Y88; VX3720 Appliance 7Y92; ThinkSystem SD530
Die oben gennanten Informationen/Spezifikationen sind Richtwerte und können ohne vorherige Ankündigung vom Hersteller geändert werden. Die Abbildungen sind nur indikativ und es können Schreibfehler vorkommen. Bitte beachten: Deutsche Bedienungsanleitung nicht im Lieferumfang enthalten. Einige Texte wurden möglicherweise automatisch erstellt oder maschinell übersetzt und können daher irreführend sein.
Günstigste Versandoption 4,99 €
Bestellware - 12-14 Tage Lieferzeit
Security policy
SSL Certificate available for secure payments
SSL Certificate available for secure payments
Delivery policy
Shipping home safely
Shipping home safely
Customer service
Customer service available 24/7
Customer service available 24/7
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LOM adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers. The Intel Ethernet Connection X722 shares the same core and drivers as the Intel X710 adapters making driver management easier of existing customers.ThinkSystem LOM adapters are cost-effective adapters that take advantage of the X722 controller embedded in Intel Xeon Processor Scalable Family chipset and offer the flexibility advantages of a PCIe adapter while supporting integrated networking features, such as Wake-on-LAN and direct connectivity to the XClarity Controller management processor for NC-SI-compliant systems management.
| Generell | |
| Hersteller: | Lenovo |
| Waren-Nr.: | 3248650 |
| Modell: | 7M17A04001 |
| EAN: | 0889488432172 |
| Zum Hersteller:: | lenovo.com |
| Kontaktieren Sie den Hersteller: | www.lenovo.com/dk/da/contact/?orgRef=htt... |
| Produktbeschreibung: | Lenovo ThinkSystem EIOM module - Netzwerkadapter - LAN-on-motherboard (LOM) - 10Gb Ethernet x 8 |
| Gerätetyp: | Netzwerkadapter |
| Formfaktor: | Plug-in-Karte |
| Schnittstellentyp (Bustyp): | LAN-on-motherboard (LOM) |
| Ports: | 10Gb Ethernet x 8 |
| Verdrahtungstyp: | Ethernet 10GBase-T |
| Data Link Protocol: | 1GbE, 10GbE |
| Datenübertragungsrate: | 10 Gbps |
| Kapazität: | Virtuelle Funktionen: 128 |
| Prozessor: | 4 x Intel X557-AT2 |
| Produktzertifizierungen: | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg |
| Systemanforderungen: | Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, VMware ESXi 6.5, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 12 SP2, VMware ESXi 6.0 update 3 |
| Entwickelt für: | ThinkAgile HX3721 Certified Node 7Y88; VX3720 Appliance 7Y92; ThinkSystem SD530 |
| Allgemein | |
| Gerätetyp: | Netzwerkadapter |
| Formfaktor: | Plug-in-Karte |
| Schnittstellentyp (Bustyp): | LAN-on-motherboard (LOM) |
| Netzwerk | |
| Ports: | 10Gb Ethernet x 8 |
| Anschlusstechnik: | Kabelgebunden |
| Verdrahtungstyp: | Ethernet 10GBase-T |
| Data Link Protocol: | Gigabit Ethernet, 10 Gigabit Ethernet |
| Datenübertragungsrate: | 10 Gbps |
| Kapazität: | Virtuelle Funktionen: 128 |
| Remoteverwaltungsprotokoll: | RMON |
| Leistungsmerkmale: | Flusskontrolle, VLAN-Unterstützung, WOL, IPv6-Unterstützung, QoS, RDMA-Unterstützung, VMDq, PXE-Unterstützung, LSO, RSS, UEFI-Support, SR-IOV, LACP, Energy Efficient Ethernet, CoS, gekennzeichnetes VLAN, MSI-X, TCP-/IP-Prüfsummen-Offload, UDP-/IP-Prüfsummen-Offload, VEPA, NC-SI, VXLAN, NVGRE, VEB, TPH, Advanced Packet Filtering, Intel VT, Jumbo Frame-Unterstützung (bis zu 9728 Bytes) |
| Produktzertifizierungen: | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg |
| Prozessor / Arbeitsspeicher | |
| Prozessor: | 4 x Intel X557-AT2 |
| Erweiterung/Konnektivität | |
| Schnittstellen: | 8 x 1Gb Ethernet/10Gb Ethernet - RJ-45 |
| Verschiedenes | |
| Kennzeichnung: | ICES-003 Klasse A, RoHS, UL 60950-1 Second Edition, FCC Part 15 A, KCC Class A, VCCI Class A, RCM, RRA Class A |
| Software / Systemanforderungen | |
| Software inbegriffen: | Intel PROSet |
| Erforderliches Betriebssystem: | Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, VMware ESXi 6.5, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 12 SP2, VMware ESXi 6.0 update 3 |
